Description
Product Description
YFI-1 Digital Battery Capacity Tester LCD Display Battery Power Indicator Current Detection Module/Sensor
Introduction
Product model: YFI-1 Product function: Detect the input current, if the input current exceeds the set value, control the output power off. Used for motor blocking and turning current protection; The current is too large protection and other occasions. During the period when the current value increases at the beginning of detection; There is a startup of 2 seconds; Filter out the large current fluctuation caused by the inductive load of the motor. Setting range: 0.01A-10A Power supply voltage: DC: 7-24V general purpose. Wiring description: pluggable wiring; The input number of volts, the output is how many V, the output control positive electrode on and off. Product size: Shell 70cm*45cm*28cm Setting instructions: + : current upper limit increases - : current upper limit decreases when the output end is suspended; Hold down "+, -" at the same time: error calibration, current return to 0.
