Description
Product Overview
The QXMC series is a hydrostatic pressure level transmitter for measuring the level of liquids in various tanks and other types of vessels. The EC hydrostatic pressure level transmitter consists of a piezo resistive sensor and Wheatstone bridge to directly measure head pressure exerted on the diaphragm of the EC level transmitter. When the pressure is exerted on the diaphragm, as a result of the liquid level, the pressure is transferred to the Wheatstone bridge electrical circuit through silicon oil contained in the EC sensing unit. This creates a differential voltage, which is then amplified to create a variable 4-20mA output that varies as a result of the changing liquid level. In addition, a pressure transducer is available for measuring pressure in tanks or pipes and producing a variable 4-20mA output.
Features: Completely submersible liquid level transmitter Wide variety of sensors, e.g. extension tube or flexible cable, standard or high temperature Measuring range up to 328ft (100m) 4-20mA output, 2-wire loop powered Pressure transducer also available Applications: USE Extension cable unit can measure in deep wells or reservoirs Tank level measurement and control PLC or DCS input for level control functions Pressure measurement of gas or liquid (EC1500) INDUSTRY Water treatment and distribution Chemical Many others
