Description
Details Images
Specification
Main Specifications
|
||
Model
|
EG-B3
|
|
Certifications
|
FCC, CE, RoHs, SRRC
|
|
Performance Specifications
|
||
Frequency Range
|
840MHz~960MHz, adjustable
|
|
Protocol
|
EPC C1G2, ISO18000-6B/C
|
|
Chip
|
Impinj R2000
|
|
Frequency band
|
GB 920MHz~925MHz, 840MHz-845MHz; FCC 902MHz~928MHz;
|
|
Optional frequency band
|
Please tell our sales which band do you want before ordering: ETSI865MHz~868MHz; JP 916.8MHz~920.4MHz;TW922.25~927.75MHz;
ID923.125~925.125MHz; RUS, 866.6~867.4 MHz; TEST, 802.75~998.75MHz; JP_LBT,916.8~920.8MHz |
|
Communication protocol
|
TCP/IP
|
|
Functions
Functions |
RFID read&write/visible and audible alarm/infrared sensor/incoming or outgoing record/People Counting
|
|
Reading Distance
|
0-20 meters, adjustable
|
|
Antenna port
|
4 TNC ports
|
|
I / O interface
|
2 inputs, 3 outputs
|
|
Working mode
|
Fixed frequency/frequency hopping optional
|
|
RF output power (port)
|
33dBm±1dBm(MAX)
|
|
Recognizing speed
|
>600 times / S
|
|
Communications
|
||
Communication
|
COM port or network
|
|
RS232
|
Baud rate support 9600, 19200, 115200 (default), 460800 optional;
|
|
Physical Specifications
|
||
Dimension
|
1495(H)*450(L)*180(D)mm
|
|
Screen
|
10.1 touch screen (optional, not standard)
|
|
resolution
|
1366*788
|
|
screen ratio
|
16:9
|
|
Net weight
|
50kg
|
|
Material
|
Aluminum and Acrylic
|
|
Installation Method
|
Fixed on the floor. Contact our sales for installing guide or check the introduction video.
|
|
Optional Functions
|
||
OS
|
Windows (optional for Android)
|
|
Screen
|
10.1 touch screen(optional)
|
|
Mini PC
|
N29,2G RAM ,32GROM(RK3399, 2G+8G)
|
|
Power
|
||
Power Supply
|
220V, 10A, 50Hz
|
|
Power consumption
|
120W (output power 33dbm)
|
|
Operating Environment
|
||
Operating temperature
|
-20 ºC ~+60 ºC
|
|
Storage temperature
|
-40℃~+85℃
|
|
Working humidity
|
<95% (+25°C)
|
Why Choose Us
Packing & Delivery
Package: Normally it is packed with wooden case.
Delivery: We support air and sea shipping and will take different method according to the products dimension and weight. And of course, we will choose shipping method according to your request. Besides, you can also use you own shipping forwarder if you have one.Applications
FAQ
1.What is your minimum order?
Our RFID reader MOQ is 1 unit.
2.What is your lead time?
Our normally lead time is 1~7 working days,also depends on real order quantity and specific requirement.
3.What method will you use for shipment?
We delivery goods by DHL,FedEx,TNT,UPS ,also can ship goods by sea or by air,real method depends on order quantity.
4.What payment methods your company accept?
We can accept payment by T/T, Western Union and paypal.
5.How to place order to you?
You can send online order on Alibaba platform,also can send purchase order to our sales directly ,we will send online or offlineproforma invoice to you confirm order.
6.Can you provide after-sales technical support?
Yes,we have strong technical team can provide after sale technical support service.
7.Why choose you?
manufacturer specialized in UHF RFID produccts. Our products including RFID readers, RFID doorway, RFID cabinet,RFID antenna and RFID tags. I am sure our product line can cover your needs.
