Product Description
Basic Info.
Product Description
Features:
1. Support tags conforming to standards EPC global UHF ISO-18000-6C (EPC G2);
2. Frequency range 865-868mhz; 902~928MHZ(or customized);
3. Support multi communication interfaces (LAN,TCP/IP, RS232, RS485, Wiegand26/34);
4. 7dbi circular polarization antenna, the height of antenna adjustable;
5. RF output power 20 ~ 30dBm adjustable, support auto, command, trigger work modes;
6. Reliable industry structure design, workable in varied severe environment.
|
Frequency
|
US:902-928mhz; EU:865-868Mhz
|
|||
|
Protocol
|
ISO18000-6C (EPC GEN2 CLASS ONE) ,ISO 18000-6B
|
|||
|
Gain
|
7dBi
|
|||
|
Operation Mode
|
Fixed Frequency Or Software Control
|
|||
|
RF Power
|
0-30dBm, Software Control and adjustable
|
|||
|
Working Mode
|
Passive and active for reading ,can control by software
|
|||
|
Communicate Port
|
Wiegand26/34/98.Rs232,Rs485,TCP/IP
|
|||
|
Input Interface
|
1 way Trigger input
|
|||
|
Reading range
|
1-4M
|
|||
|
Working Model
|
LED Light (Green), Red LED When Alarm
|
|||
|
Power Supply
|
DC+220v+-10%
|
|||
|
Size
|
380*62*1440mm
|
|||
|
Weight
|
76kg/Pair With Package Wooden Box
|
|||
1. What is MOQ?
Mind makes OEM, so the MOQ is 1pcs
2. Can I order the gate with customized ?
Yes we support function OEM and ODM based on requirement
3. Can I get Free Samples?
For RFID stickr /Lable and tags lower value produce can support
4. Can I order with my logo printing, size and shape?
Yes, of course it can. We do OEM. And the original artwork prefer in Abode Illustrator, PDF, CDR9 or CDRX4. In PSD is ok, DPI should over 300.
Quick to solve problems, creative to design new items, newest RFID items are available here.
Cost-effective and flexible to adjust production for volume and urgent orders.
5.How do you guarantee the printing color correctly?
At least 95% matched color with customer vector design file/original card for CMYK 4c printing, pantone printing and silk-screen printing.
