Description
Product Description
Specification
| Basic parameters | |
| Machine size | 164.2mm x 78.8.0mm x17.5mm |
| Wight | 288g (standard configuration) |
| Display | 5.2 Inch, IPS FHD 1920x1080 Resolution |
| Touch Screen | Corning Gorilla Glass, supports multi-touch, support gloves or wet hands |
| Expansion slot | 1 SIM Slot |
| One card slot SIM or TF (pick one of two) | |
| Communication interface | USB 2.0 Type-C, OTG; Octa-core version supports Type-C headset |
| Audio | Speaker, 2 microphones |
| Keyboard | 4 main keyboards, 1 power button, 2 scan buttons, 1 muti-function button |
| Camera | 13 megapixel color camera with auto focus and flash |
| GPS Navigation | Built-in GPS global positioning system with an error range of ±5m |
| Senor | Gravity sensor, light sensor, distance sensor |
| Performance Parameters | |
| CPU | Cortex-A53 2.5/2.3GHz octa-core |
| Memory Capacity | 3GB+32GB/4GB+64GB/6+128GB mass storage options |
| Operation System | Android 8.1/ 11.0 operating system; supports Soti MobiControl, SafeUEM, etc. |
| Development Environment | |
| SDK | Terminal software development kit |
| Development Language | Java |
| Development Tools | Eclipse / Android Studio |
| Extended Memory | MicroSD (TF)Card Can Extend to 128GB |
| Data communication | |
| WLAN | Support IEEE802.11 a/b/g/n protocol, (2.4G/5G dual frequency); built-in antenna |
| WWAN（Android 8.1） | 2G: 900/1800MHz 3G: WCDMA：B1/B8 CDMA2000 EVDO:BCO TD-SCDMA：B34/B39 4G: TDD-LTE: B38, B39, B40, B41 FDD-LTE: B1, B3, B5，B8 |
| WWAN（Android11.0） | 2G：GSM850/GSM900/DCS1800/PCS1900 3G:WCDMA：B1/B2/B4/B5/B8 CDMA2000 EVDO:BCO TD-SCDMA：A/F 4G:B1/B2/BB3/B4/B5/B7/B8/B12/B17/B20/B28A/B28B/B34/B38/B39/B40/B41 |
| Bluetooth | Android8.1：Bluetooth V2.1+EDR,3.2+HS，V4.1+HS Android11.0；Bluetooth 5.0 |
| GNSS | Integrated GPS, GLONASS and Beidou; built-in antenna, support AGPS |
| Working Environment | |
| Operation Temperature | -20℃～50℃ |
| Storage Temperature | -40℃～70℃ |
| Relative humidity | 5%～95% Non-condensing |
| Drop specification | In the operating temperature range, all 6 sides can withstand multiple (at least 20) drops from a height of 1.8 meters to the concrete floor |
| Rolling test | Rolling 1000 times in a row of 0.5 meters, 6 face contact surfaces are still running stably after rolling, reaching IEC rolling specifications |
| Static Protection | ±15KV air discharge, ±6KV contact discharge |
| Protection level | Host IP65, up to IEC seal standard |
| Battery performance | |
| Battery Capacity | Rechargeable lithium polymer battery 5000mAh |
| Standby Time | >350 hours |
| Charging Time | 3-4 hours (using the standard power adapter and data cable) |
| Working Time | > 12 hours (depending on usage and network environment) |
| Bar code collection (optional) | |
| Bar code scanning engine | Zebra SE965 / Honeywell N4313 |
| Support 1D type | CPU/EAN,Code128，Code39，Cod,11，Interleaved2of5，Discrete 2 of 5，Chinese 2 of 5，Codabar,MSI,RSS etc. |
| 2D Bar code collection (optional) | |
| Two-dimensional scanning engine | Zebra: SE4710 / SE4750 / SE4750MR; Honeywell: N6603 |
| Support 2D type | PDF417, MicroPDF417, Composite, RSS, TLC-39,Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes,US PostNet,US Planet, UK Postal, Australian Postal,Japan Postal, Dutch Postal(KIX) etc. |
| UHF RFID（Optional） | |
| Support Frequency | 915MHz, 865MHz（865-868MHz or 902-928MHz） |
| Support Protocol | EPC C1 GEN2 /ISO18000-6C Protocol |
| Read Distance | ＞1.5 meter（Circular polarization, indoor) |
| Group read rate | ＞150 Label per second (circular polarization) |
| Power | 1W（27dBm, Support +19dBm ~ +27dBm adjustment) |
| RFID Module | VM-5S, Built in pr9200 |
| Antenna Parameters | Linearly polarized antenna（1dBi） |
| HF RFID（Optional） | |
| Support Frequency | 13.56MHz |
| Support Protocol | For ISO15693, ISO14443A/B protocol |
| Read Distance | 2-4CM(Depend on labels and the environment) |
| Iris recognition (optional) | |
| Recognition time | <150ms |
| Working distance | 20-40cm |
| FAR | 1/10000000 |
| Protocol Standard | ISO/IEC 19794-6, GB/T 20979-2007 |
| Package list | Lithium battery, charging head, DC charging cable, USB charging cable |
| Tips: | For more information, please consult online customer service, thank you | ||||||
Application and Cases
FAQ
Q: You are factory or trading company?
A: We are an original manufacturer for over 15 years.
Q: How is your QC?
Q: How is your QC?
A: We have strict QC process and all the products will be 100% testing before shipping.
Q: What is your payment term?
Q: What is your payment term?
A: 100% payment should be paid before shipping.
Q: What is your payment way?
Q: What is your payment way?
A: Bank Transfer T/T, Western Union, Alibaba Pay
Q: What is your warranty?
Q: What is your warranty?
A: One year.
Q: Can I get technical support from you?
Q: Can I get technical support from you?
A: Sure. Our sales are of all good knowledge in the field. Besides, we have a technical team to support.
