Description
Product Overview
Series Intelligent Battery Charger
LD series DC servo motor driver is a high-performance DC motor driver which has been introduced by senior experts after more than ten years of application experience in the robot industry, combined with leading motor control and current accurate detection technology. The powerful PID adjustment technology can perfectly control the motor's smooth forward and reverse rotation, commutation and braking. The output current can be adjusted in real time to prevent overcurrent. The motor speed and rotation position can be accurately controlled. The motor has a short response time and low recoil. We can provide 5A-200A high current, wide voltage input 12v-96v and other serialized products. This product is widely used in mobile cars, service robots, wearable exoskeleton robots and other products.
Product specifications
Item
Parameters
Rated input power supply 50Hz
Single phase 220
Rated output power
2.9kW
Input current
15.3A
Rated output current
50A
Rated output voltage
58.4V
Main engine net weight
72kg
Net weight of side charging Device
/
Communication method
CAN/ support other correspondence way customized
Protection grades
IP21
Outline dimension
772*500*1262(mm)
Product Advantages
Modular Design
The modular design， high conversion efficiency and high power factor, can be applied to various AGV solutions. It has both automatic charging and manual charging functions (reverse connection is strictly prohibited during forced charging).
The integrated design of the charging station, with an automatic telescopic mechanism, is quick and easy to install (there is also a split type).
The charger is equipped with a 7-inch touch screen, which can realize the functions of charging process control, charging status display, charging data recording and fault information recording.
