OPA544 internal current limit thermal shutdown protection sound amplifier speaker prosound amp home stereo power amp
Parameter
| Name | OPA549 Audio Power Amplifier |
| Size | 86mm*81mm*52mm |
| Supply voltage range | ±10V~±30V |
Highlights
High-voltage, high-current audio power amplifiers can continuously output 8A with a maximum peak value of 10A, ideal for driving various loads such as motor drives, speaker drivers, transformer drivers, and audio amplifiers. It can also amplify triangular, sine, and square wave signals.
Chip description
The OPA549 is a low cost, high voltage, high power op amp ideal for driving a wide range of loads. The regional laser trimming monolithic integrated circuit provides the accuracy of a low level signal and high output voltage and current. The OPA549 design is flexible enough to support single or dual power operation. The input common film range extends below the negative supply.
The OPA549 is protected by internal temperature and electrical overload. In addition, the OPA549 provides accurate, user-selectable, electric madness. Unlike other uses in series with the output electrical channel"
The power “resistance, 0PA549 indirectly senses the load. This allows it to be electrically adjusted from 0A to 10A through a resistor/potentiometer, or digitally through a voltage or electrical output digital-to-membrane converter (DAC). The Energy/Status (E/S) pin provides two functions. It can be monitored to determine if the device is thermally shut down, and can force a low disable auxiliary stage and effectively disconnect the load.
The 0PA549 is a power package for the 11-lead pin. Its copper label can be easily mounted on the heat sink due to its excellent heat recovery. Operation specified in the extended industrial temperature range, 40C to 85°C.
Chip features
High output current: 8a continuous/10a peak
Wide Supply Range: Single Supply: +8V to +60V
Wide output voltage swing
Full protection: thermal shutdown/adjustable current limit
Output cannot be controlled
Thermal shutdown indicator
High conversion rate: 9V/us
Control reference pin
11-lead power package
Dual Supply: ±4V to ±30V
Chip application
Valve, drive drive
Synchronous servo drive
power supply
Test equipment
Transducer excitation
Audio power amplifier
