OEM Smart Watch GPS Tracker PCB Circuit Board Mini Tracking System Device PCBA Assembly Manufacturing

GPS Module
$5.87
Quantity
Contact us

Get in touch

Please email us at sale1@rfid-life.com with a detailed overview of your project requirement. So that we can offer you the fastest and best support. You may expect a reply within 24 business hours. – Welcomes Your Comments And Questions.


Sales Department

Phone: +86 18205991243
Whatsapp: +86 18205991243
Telegram: +86 18205991243
Email: sale1@rfid-life.com
Address: No.987,High-Tech Park,Huli District,Xiamen,China


Support Department

Email: support@rfid-life.com


Business Hours

Monday - Friday 9am to 6pm

Saturday - 9am to 12am

Sunday - Closed

Description

Product Description:

OEM Smart Watch GPS Tracker PCB Circuit Board Mini Tracking System Device PCBA Assembly Manufacturing

Product Description
NO. PCB, PCBA print circuit boards Manufacture capacity
1 Layer Counts 1-8Layer
2 Base Material PI / FR4 / PET / Steel piece
3 Copper foil thickness 1/3oz to 3oz
4 Board thickness 0.4-3.2mm
5 Max. board size 400*800 mm
6 Product thickness tolerance    ±0.03mm
7 Min. Hole Diameter 0.2mm
8 Min.Line Width/ Distance 0.1mm
9 Etching tolerance   ±0.015mm
10 PTH Hole dia. tolerance ±0.03mm
11 NPTH Hole dia. tolerance ±0.05mm
12 Outline Dimension   tolerance   ±0.075mm
13 Outline profile Punching / Laser cut / Drilled
14  Surface finish    HASL / OSP / ENIG / Immersion Gold/Silver/Tin/Ni
15 Solder mask color Yellow/ Green, as request
16 Silkscreen color   White/Black, as request



17

Acceptable file format CAD / Gerber file / powerpcb / Autocad Orcad/ P-cad / CAM-350 / CAM2000
