Consumer-grade tablets might appear to be cost-effective because the price is right. But the lack of healthcare features adds safety concerns and costs — from the inability to disinfect to prevent the spread of germs to the need to purchase scanners for barcode capture and more frequent device replacements due to lack of durability. Industrial tablets come with many perks that consumer-grade tablets don’t have. Most industrial solutions are used in tough work environments such as warehouses, manufacturing, logistics, construction, transportation, and more. This means more risk of damaging the device by drops, dirt, dust, or spills. Hence, industrial tablets come with a rugged design and typically have Ingress Protection (IP) ratings that showcase their level of resistance to water, dirt, and other particles. Also, many industrial tablets use hot-swappable batteries. This makes it easier for the operator to continue working if the battery unexpectedly dies. When it comes to screen size, premium industrial tablets have an additional layer that allows glove-on manipulation. Overall, thanks to less repair-related costs, industrial tablets have a lower total cost of ownership (TCO) compared to consumer models. When choosing an industrial tablet, watch out for the type of screen you’re getting. Capacitive screens don’t support glove usage and will make your construction or warehouse tablet purchase less successful. The HC805 with Android 13 is a newly upgraded rugged tablet that has abundant functions. With its powerful Octa-core CPU, 8-inch high definition screen, 8000mAh battery and comprehensive data capture options like UHF RFID, barcode scanning, fingerprint recognition, NFC, etc., you can find this easy-to-deploy device a valuable helper to increase productivity in retail, logistics,warehousing, identity verification, etc.
|
Physical Characteristics
|
||
|
Dimensions
|
248 x 170 x 17.8mm / 9.76 x 6.7 x 0.7 in
|
|
|
Weight
|
~15.87 oz./~450 Grams (device with battery)
|
|
|
Display
|
8-inch, IPS 1920 x 1200
|
|
|
Battery
|
Main battery: Li-ion, rechargeable, 10000mAh
Standby: over 500 hours Continuous use: over 10 hours (depending on user environment) Charging time: 6-8 hours (with standard adaptor and USB cable) |
|
|
Touch Panel
|
Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported
|
|
|
Notification
|
Sound, LED indicator
|
|
|
Interfaces
|
USB 2.0, Type-C, OTG
|
|
|
Expansion Slot
|
1 slot for Micro SIM card, 1 slot for MircoSD(TF) or PSAM card (optional)
|
|
|
Audio
|
2 microphones，1 for noise cancellation；1 speaker；receiver
|
|
|
Keypad
|
3 TP soft keys, 3 side keys, numeric keyboard (Optional : 20 keys)
|
|
|
Sensors
|
Gravity sensor; gyroscope; geomagnetic sensor (Optional); light / proximity sensor (Optional)
|
|
|
Communication
|
||
|
WLAN
|
IEEE802.11 a/b/g/n/ac, 2.4G/5G dual-band, internal antenna
|
|
|
WWAN (Europe, Asia)
|
2G: 850/900/1800/1900 MHz
2G: 850/900/1800/1900 MHz WCDMA: 850/900/1900/2100MHz TD-SCDMA: A/F(B34/B39) 4G: B1/B3/B5/B7/B8/B20/B38/B39/B40/B41 |
|
|
WWAN (America)
|
2G: 850/900/1800/1900 MHz
3G: 850/900/1900/2100 MHz 4G: B2/B4/B5/B7/B8/B12/B13/B17/B28A/B28B/B38 |
|
|
Bluetooth
|
Bluetooth 4.0
|
|
|
Vo-LTE
|
Support Vo-LTE HD video voice call
|
|
|
GNSS
|
GPS/AGPS, GLONASS, BeiDou, Galileo, internal antenna
|
|
|
Developing Environment
|
||
|
Operating System
|
Android 13; GMS, 90-day security updates, FOTA, Soti MobiControl, SafeUEM supported
|
|
|
SDK
|
Support Android/iOS
|
|
|
Language
|
Java
|
|
|
Tool
|
Eclipse / Android Studio
|
|
|
Performance
|
||
|
CPU
|
MTK 6762 - 8 Core
|
|
|
RAM+ROM
|
3 GB + 32 GB / 4 GB + 64 GB
|
|
|
Expansion
|
Supports up to 128 GB Micro SD card
|
|
|
Barcode Scanning (Optional)
|
||
|
2D Scanner
|
Zebra SE4710; Honeywell N6603
|
|
|
1D Symbologies
|
UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.
|
|
|
2D Symbologies
|
PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US
Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX),etc. |
|
|
NFC
|
||
|
Frequency
|
13.56 MHz
|
|
|
Protocol
|
ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.
|
|
|
Chips
|
M1 card (S50, S70), CPU card, NFC tags, etc.
|
|
|
Range
|
3-5 cm
|
|
|
User Environment
|
||
|
Drop Specification
|
Multiple 6 ft./1.8 m drops to concrete
|
|
|
Tumble Specification
|
500 cycles (1000 drops, 1.6 ft./0.5 m) at room temperature
|
|
|
Operating Temp.
|
-4°F to 131°F / -20 ℃ to +55 ℃
|
|
|
Storage Temp.
|
-40°F to 158°F / -40 ℃ to +70 ℃
|
|
|
Humidity
|
5 - 95% RH non condensing
|
|
|
Sealing
|
IP65 (spray) and IP67 (submersion)
|
|
|
ESD
|
±15 KV air discharge, ±8 KV conductive discharge
|
|
|
Engine
|
CM710-1 module based on Impinj E710
|
|
|
CM510-1 module based on Impinj E510
|
||
|
CM2000-1 module based on Impinj Indy R2000
|
||
|
Frequency
|
865-868 MHz / 920-925 MHz / 902-928 MHz
|
|
|
Protocol
|
EPC C1 GEN2 / ISO18000-6C
|
|
|
Antenna
|
Circular polarization; UHF with pistol grip, 4dBi
|
|
|
Power
|
1W ( 30dBm, +5dBm to +30dBm adjustable )
|
|
|
2W Optional ( 33dBm, for Latin America, etc. )
|
||
|
Max Read Range
|
Up to 15 m (open outdoors, Impinj MR6 tag)
|
|
|
Fastest Read Rate
|
900+ tags/sec
|
|
|
Note
|
* UHF with pistol grip
* Ranges and rates depend on tags and environment |
|
