UHF Blue tooth Reader
General Description:
It is a high performance UHF RFID Reader & Writer. It is designed upon fully self-intellectual property. Based on proprietary efficient digital signal processing algorithm, it supports fast tag read/write operation with high identification rate. It can be widely applied in many RFID application systems such as logistics, access control, attendance system, anti-counterfeit and industrial production process control system.
Application:
u Sports card reader management
Features:
1. Self-intellectual property;
2. Support ISO18000-6C (EPC C1G2) protocol tag;
3. 865~868MHz, 902~928MHz frequency band (frequency customization optional by Soft);
4. FHSS or Fix Frequency transmission;
5. RF output power up to 26dBm (adjustable);
6. 2dBi Circular PCB antenna with effect distance up to 0cm~60cm*;
7. Support active mode, answer mode;
* Effective distance depends on antenna, tag and environment.
Product mode explanation:
|
Model |
Interface |
|
1903B |
USB HID & Blue tooth(BLE4.2) |
|
–B Blue tooth |
|
Characteristics:
Absolute Maximum Rating
|
ITEM |
SYMBOL |
VALUE |
UNIT |
|
Power Supply |
VCC |
5 |
V |
|
Operating Temp. |
TOPR |
-20~+60 |
℃ |
|
Storage Temp. |
TSTR |
-40~+85 |
℃ |
Electrical and Mechanical Specification
Under TA=25℃,VCC=+5V unless specified
|
ITEM |
SYMBOL |
MIN |
TYPE |
MAX |
UNIT |
|
Power Supply |
VCC |
|
5 |
|
V |
|
Current Dissipation |
IC |
|
200 |
300 |
mA |
|
Frequency |
FREQ |
865 |
|
928 |
MHz |
Product Technical Parameters
|
Type |
|
|
Type |
UHF Blue tooth Reader |
|
Physical parameters |
|
|
Dimensions |
140x69x15mm |
|
Net Weight |
60g |
|
Gross Weight |
0.3Kg |
|
Package size |
20*10*5cm |
|
Shell material |
ABS |
|
Color |
Grey, White |
|
Environmental parameters |
|
|
Operation Temperature |
-20~+60℃ |
|
Storage Temperature |
-40~+85℃ |
|
Humidity |
5%~95% RH, Non-condensing |
|
Performance |
|
|
Frequency |
902~928MHz,860~868MHz(frequency customization optional) |
|
Ant. |
2dBi Circular PCB antenna |
|
RF Power |
0 - 26dBm |
|
Read Distance * |
0-60cm * Effective distance depends on antenna, tag and environment. |
|
Write Distance * |
0-30cm * Effective distance depends on antenna, tag and environment. |
|
Read Rate |
200cnt / second |
|
Read Type |
ISO18000-6C(EPC Gen2) |
|
Reading Prompt |
Buzzer, LED |
|
Working Voltage |
USB,200mA/2000hA battery rechargeable battery |
|
Work Mode |
Active mode, Answer mode |
|
Communication |
SW1903B: USB HID & BLE4.2& Battery
|
|
SDK |
|
|
SDK |
Support X86 & X64, C++, C#, VB, Delphi, Linux, ARM, Python, NodeJS, QT, JAVA, Android. |
