Working voltage : DC 6-25V(Perfect for 6V 9V 12V 18V 24V LED Driver)
Output Current: 30-900MA;By changing the RCS resistance, the maximum current can reach 1200MA
Maximum output power: 20W
Current regulation: 1 through adjustable resistance; 2 through PWM control
Single pin on/off and brightness control using DC voltage or PWM
Up to 1MHz switching frequency
Typical 5% output current accuracy
Inherent open-circuit LED protection
High efficiency (up to 97%)
High-Side Current Sense
Hysteretic Control: No Compensation
Adjustable Constant LED Current
Size : 30mm x 15mm x 6.3mm
Weight : 2.5g
1. We will pack and send your goods within 2-3 working days after we confirmed your payment. For quickly packing and sending, please let us know if you finished the payment.
2. We will inform you the lead time if we have to purchase from manufactory.
3. We usually ship by DHL, UPS, TNT, FedEx, Aramex or EMS. It usually takes 3-7 days to arrive. Air cargo and sea shipping are aslo optional.
4. We are not responsible for any accidents, delays or other issues that are the responsibility of shipping service.
5. We need your shipping information including your name, address and phone number for shipping your parcel.
6. Tracking number will be shared with you when we got it from the logistics company.
About Payment Terms:
1. You can pay for your purchase order by PayPal, T/T, Western Union, Ali-escrow or Cash.
2. The unit price we provided not included any shipping fees or payment charges.
3. We are not responsible for any import fees or customs taxes.
About Quality Warranty:
1. Our products are all original and new from manufacturer. It must be work if the model number is correct.
2. We offer 30-90 days warranty to our products.
3. During the guarantee period, if the items you purchased from our store are out of perfected quality, pls notify us within 3 days after delivery, we will return the new products when we got your message.
Others:
1. MOQ: Low MOQ! We welcome 1pcs as sample order to test and check quality. Mixed samples are acceptable.
2. Unit Price: The prices we provided are based on the new and original parts. We can offer a discount according to your purchase order quantity.
