Description
Product Description
|
Physical Parameter
|
||
|
Size
|
47mm×40mm×14mm
|
|
|
Material
|
ABS+PC Transparent
|
|
|
Color
|
White (Little transparent)
|
|
|
Weight
|
20g
|
|
|
Packing
|
Corrugated box (50pcs / box) (can be customized)
|
|
|
Environmental Parameters
|
||
|
Working Humidity
|
<95%
|
|
|
Working Temperature
|
-25 ~ 70℃
|
|
|
Storage Temperature
|
-40℃~ 85℃
|
|
|
Protection Level
|
IP67 (Dust-proof and waterproof, do not soak)
|
|
|
Performance parameter
|
||
|
Static (standby) working current
|
<5uA
|
|
|
Operating Voltage
|
3.0V
|
|
|
Battery
|
CR2450 X 1 (Battery can be replaced)
|
|
|
Working Current (Transmit signal)
|
12mA (Pulse mode)
|
|
|
Battery Life
|
3～5Year (theoretical value)
|
|
|
Collision Ability
|
>200PCS
|
|
|
Transmit Time
|
Active 1 time per second / Passive 3 to 4 times per second
|
|
|
Transmit Power
|
4dBm (factory setting)
|
|
|
Working Mode
|
Read-only
|
|
|
Working Method
|
Active/Passive /Active-passive combination
|
|
|
Low/High Frequency
|
13.56Mhz (Optional)
|
|
|
Reading Distance
|
0-80m (Can be customized to 120-150m)
|
|
|
Identified by Light
|
Support
|
|
|
Anti-assemble Alarm
|
Support
|
|
|
Sound Alarm
|
Support (70DB)
|
|
Product Summary
Acousto-optic tamper-evident tags can have multiple operating frequencies. 2.4GHz can be identified from a long distance, making it more secure. The tag spontaneously transmits and returns signals, and can be recognized by the RFID long-range reader without triggering. IC / ID mode can also be added according to customer requirements.
Product Feature
● Reading: Compared with bar code, there is no need to scan in a straight line, the reading speed is faster, and multi-tag recognition and motion recognition can be performed; ● Security: Tamper resistance, encryption algorithms and authentication to ensure data security, prevent link eavesdropping and data cracking, more durable;
● Dedicated chip, unique serial number, difficult to copy. Durability without mechanical failure, fully sealed structure resistant to harsh environments.
● Tag ID number: 10 bytes;
● Reading Type: Read-only;
● Duration of use: large battery capacity and long service life;
● Waterproof: IP67;
● Reading Distance: Long range (0-80m) (Can be customized to 120-150m)
● Anti-suddenness: Advanced anti-collision technology can identify more than 200 tags at the same time;
● High speed recognition: recognition speed can reach 60 km/h;
● High anti-interference: no special requirements for various interference sources on the site;
● Anti-electromagnetic interference: 10V/m0.1 ~ 1000MHz AM, AM electromagnetic wave. ● Carry Method: Can be put into pocket or put into car.
Applications ● Location of personnel in the case handling area ● Positioning of nursing home staff ● Building, community card ● Prison card or regional personnel positioning ● Positioning of construction personnel ● Personnel access management ● School student and teacher attendance management ● Automatic identification personnel management system
