Description
Inertial Measurement Attitude Module BMI160 6 DOF Sensor Angular Velocity Accelerometer and Gyroscope Module
Product Description
High-performance accelerometers and gyroscopes (hardware-synchronized)
Ultra Low Power: Typical. 925μA (accelerometer and gyroscope full input)
Android compatible: significant action step / step counter (5 μA each)
Very small 2.5 x 3.0 mm 2 footprint, height 0.83 mm
Built-in power management unit (PMU) *** power management
Quick Start Mode of Power Saver Gyroscope
Wide supply voltage range: 3.3V ... 5V
Can allocate 1024 bytes of buffer in the FIFO (able to handle data from external sensors)
Hardware sensor timestamp for accurate sensor data fusion
Comprehensive interruption, enhanced autonomous motion detection
The flexible digital master interface is connected to the host via I2C or SPI
Extended I2C mode with clock frequency up to 1MHz
Other secondary high-speed interface OIS applications
Ability to handle external sensor data
Ultra Low Power: Typical. 925μA (accelerometer and gyroscope full input)
Android compatible: significant action step / step counter (5 μA each)
Very small 2.5 x 3.0 mm 2 footprint, height 0.83 mm
Built-in power management unit (PMU) *** power management
Quick Start Mode of Power Saver Gyroscope
Wide supply voltage range: 3.3V ... 5V
Can allocate 1024 bytes of buffer in the FIFO (able to handle data from external sensors)
Hardware sensor timestamp for accurate sensor data fusion
Comprehensive interruption, enhanced autonomous motion detection
The flexible digital master interface is connected to the host via I2C or SPI
Extended I2C mode with clock frequency up to 1MHz
Other secondary high-speed interface OIS applications
Ability to handle external sensor data
Specification
|
item
|
value
|
|
Wide supply voltage range
|
3.3V~5V
|
|
Ultra Low Power
|
Typical. 925μA
|
Details Images
