The membrane head can be replaced, saving costs.
Description
|
name
|
parameters
|
|
Output Signal
|
Supports RS485, MODBUS/RTU Protocol
|
|
Measurement Methods
|
Laminating Ion Selection Method
|
|
Measuring Range
|
0～10.0mg/L or 0～100.0mg/L (PH range 4-10)
|
|
Accurate
|
±5%F.S. or ±3mg/L, whichever is greater
|
|
Resolution
|
0.01mg/L (0 to 10.00mg/L) or 0.1mg/L (0-100.0mg/L)
|
|
Working Conditions
|
0～40℃; <0.2MPa
|
|
Calibration Method
|
Two-point calibration
|
|
Response Time
|
30 seconds
|
|
Temperature Compensation
|
Automatic temperature compensation(Pt100)
|
|
Power Supply
|
12 or 24VDC ±10%, 10mA
|
|
Protection Class
|
IP68; water depth 20 meters
|
|
Service Life
|
1 year or more for sensors; 6 months for membrane heads
|
|
Cable Length
|
10 meters (default), customizable
|
|
Sensor Housing Material
|
POM; Customizable
|
|
Wireless module
|
We can supply
|
|
Server and software
|
We can supply the cloud server and matched
|
Feature 1
Built-in temperature compensation, the output value is not affected.
Feature 3
High accuracy and stable data.
A free RS485 to USB converter and the matched test software can be send with the sensor and you can test in the PC end
Feature 5
software ( website ) to see the real time data and also the history data and alarm.
Have matched cloud server and software
The matched cloud server and software can be send if using our wireless module to see the real time data in PC or Mobile and also
can download the data in excel.
can download the data in excel.
Note: Keep the sensor mounted at a minimum tilt angle of 30° or more.
Nitrite sensors are widely used in aquaculture and agriculture, as well as wastewater and drinking water treatment and other fields
Ewage Treatment
Aquaculture
Agricultural Irrigation
1. Water PH sensor
1. The water PH sensor can be RS485 output, 4-20mA output, 0-5V, 0-10V output with high precise.
2. It can integrate all kinds wireless modules including GPRS/4G/WIFI/LORA/LORAWAN.
3. We can send the free server and software to see the real time data in the PC or Mobile.
4. It can set alarm when the value is overrun.
2. It can integrate all kinds wireless modules including GPRS/4G/WIFI/LORA/LORAWAN.
3. We can send the free server and software to see the real time data in the PC or Mobile.
4. It can set alarm when the value is overrun.
1. Optical dissolved oxygen has stable performance and high precision.
2. It can integrate all kinds wireless modules including GPRS/4G/WIFI/LORA/LORAWAN.
3. We can send the free server and software to see the real time data in the PC or Mobile.
4. It can set alarm when the value is overrun.
2. It can integrate all kinds wireless modules including GPRS/4G/WIFI/LORA/LORAWAN.
3. We can send the free server and software to see the real time data in the PC or Mobile.
4. It can set alarm when the value is overrun.
1. It is optics turbidity sensor has the advantages of low price and stable performance.
2. It can integrate all kinds wireless modules including GPRS/4G/WIFI/LORA/LORAWAN.
3. We can send the free server and software to see the real time data in the PC or Mobile.
4. It can set alarm when the value is overrun.
2. It can integrate all kinds wireless modules including GPRS/4G/WIFI/LORA/LORAWAN.
3. We can send the free server and software to see the real time data in the PC or Mobile.
4. It can set alarm when the value is overrun.
1.According to actual application scenarios, the range of ammonium ion can be customized.
2. It can integrate all kinds wireless modules including GPRS/4G/WIFI/LORA/LORAWAN.
3. We can send the free server and software to see the real time data in the PC or Mobile.
4. It can set alarm in the software when the value is overrun.
2. It can integrate all kinds wireless modules including GPRS/4G/WIFI/LORA/LORAWAN.
3. We can send the free server and software to see the real time data in the PC or Mobile.
4. It can set alarm in the software when the value is overrun.
