Description
Specifications
| Main Specifications | |
| Model | EG-B2X |
| Certifications | FCC, CE, RoHs |
|
Performance Specifications |
|
|
Frequency Range |
840MHz~960MHz, adjustable |
|
Protocol |
EPC C1G2, ISO18000-6B/C |
|
Chip |
Impinj R2000 |
|
Frequency band |
GB 920MHz~925MHz, 840MHz-845MHz; FCC 902MHz~928MHz; |
|
Optional frequency band |
Please tell our sales which band do you want before ordering: ETSI865MHz~868MHz; JP 916.8MHz~920.4MHz;TW922.25~927.75MHz; ID923.125~925.125MHz; RUS, 866.6~867.4 MHz; TEST, 802.75~998.75MHz; JP_LBT,916.8~920.8MHz |
|
Communication protocol |
TCP/IP |
|
Reading Distance |
0-10 meters, adjustable |
|
Antenna gain |
9dBi |
| Working mode | Fixed frequency/frequency hopping optional |
| RF output power (port) | 33dBm±1dBm(MAX) |
| Recognizing speed | >600 times / S |
|
Physical Specifications |
|
|
Communication |
COM port or network |
|
RS232 |
Baud rate support 9600, 19200, 115200 (default), 460800 optional; |
|
Physical Specifications |
|
|
Dimension |
600*300*58.5mm |
|
Net weight |
3kg |
|
Material |
Aluminum+Acrylic |
|
Installation Method |
Fixed with installation bracket |
| Power | |
| Power Supply | 12V/3A |
| Power consumption | 20W (output power 33dbm) |
| Operating Environment | |
|
Operating temperature |
-20 ºC ~+60 ºC |
|
Storage temperature |
-40℃~+85℃ |
|
Working humidity |
<95% (+25°C) |
