FST800-1500 High Quality Firstrate Pressure Sensor Pressure Measuring Instruments
Product Description
| Measuring medium | Water |
| Pressure range (bar) | 10,16,25 |
| Signal output | 0.5~4.5VDC 4~20mA |
| Signal line specifications | 3 Wire 2 Wire |
| Supply voltage | 5VDC 9~30VDC |
| Precision | ±1%FS |
| Total error band | ±3%FS |
| Operating temperature | -40~+135℃ |
| Storage temperature | -40~+150℃ |
| Overload pressure | 200%FS |
| Breaking pressure | 300%FS |
| Vibration | 11g(50~2000Hz) |
| Supply current | 10mA (maximum) |
| Output response | 3mS |
| Service life | 5 million full-scale cycles |
| Short circuit protection | Have |
| Pressure port | G1/4,NPT1/4,M20x1.5,M12x1.5,NPT1/8 |
| Electrical connections | Packard connector |
| Load Resistance | 10KΩ (typical) |
| Protection level | IP65 |
| Overvoltage protection | 16VDC (5V power supply) |
| Material | 304 stainless steel |
| Reverse voltage | -14VDC (5V power supply) |
