Description
Product Description

DIEN36PA Isolation DC-DC Boost-Buck Converter 5-32 to +-12V 15V 24V 30V for Car Audio Speaker





Description:

2 in 1 Isolated DC-DC Boost-Buck Converter

Input Voltage Range: 5-32 VDC

Output Voltage :  ±12V/+24V(MAX 700MA); ±15V/+30V(MAX 550MA)

Minimum Load Requirements: 0% (as+24V/+30V Output), 10% (as +-12/+-15 Output)

Efficiency : 70%-88%

Quiescent current : 68mA(Input 12V)

Low Noise : 50mV

Hihg Accuracy :+/-1%

Working frequency 400KHz

Isolation (Input to Output): 1500VDC minimum (1 minute)

Isolation Capacitance: 1200pF

Short Circuit Protection

Operating ambient temperature : -40~+85 Degrees Celsius

Storage Temperature Range: -55 to +125  Degrees Celsius

Size : 68 x 44 x 16mm

Weight :  39g(With terminal), 34g(no terminal)


Pin description:
VIN    :  Input positive
GND  :  Input negative
EN     :  Input enable (NC or VIN enable, GND disabled)
V+     :  Isolated output positive voltage
COM  :  Isolated output common
V-      :  Isolated output negative voltage


Applications

ADC/DAC/Operational Amplifier
RS232 RS485 RS422 Bus
Audio equipment
Low power audio power supply
Car audio amplifier dual power board
LCD power supply
Instrumentation equipment
Instrumentation multimeter

Attention :

This is a DC-DC voltage converter module,Must be noted when using:

1 Input voltage can not be greater than the maximum input range
2 Output power can not be greater than the maximum load for a long time
3 Input power must be greater than the output power, because the power consumption of the module itself
