1 Working voltage: DC 12V
2 Working current: standby 6MA, relay conduction 35MA
3 Bluetooth protocol: BLE 5.2
4 2.4GHz-2.48GHz unlicensed ISM band
5 Send commands through the Bluetooth APP to control the on and off of the relay (we provide Android Bluetooth APP, you can also use your own APP to control the relay, you can control the relay by sending simple commands), or you can control the relay through the button.
6 Commands: ON, OFF, Delay. The ON and OFF commands can be modified
7 Size: 60*29*19MM
8 Weight: 20 grams
9 Maximum load: 10A/250VAC, 10A/125VAC, 10A/30VDC, 10A/28VDC, 10A/12VDC
For more information, please contact me
Command (Format: String)
ON : AT+O1(can be modified)
OFF : AT+C1(can be modified)
Delay : D1=XXXX(XXXX:0001~9999)
