Description
Products Description
|
Material
|
PVC/PET/ABS
|
||||||
|
Size
|
85.5*54mm or customized
|
||||||
|
Thickness
|
0.76mm-0.9mm or customized
|
||||||
|
Chip
|
Refer to RFID chips options as below. Please also consult our sales person for more information.
|
||||||
|
Frequency and reading distance
|
LF, 125KHz, 0cm≤Reading distance≤10cm
HF, 13.56MHz, 0cm≤Reading distance≤10cm UHF, 860-960MHz, 0cm≤Reading distance≤10m |
||||||
|
Printing
|
a. Offset Printing/CMYK printing (Heidelberg offset printing machine)
b. Digital printing (HP digital Printing machine)
c. Silk-screen printing d. Glossy/Matt/Frosted surface with overlay |
||||||
|
Crafts
|
a. Glitter gold/silver background
b. Loco 300oe/600oe magstripe , Hico 2750oe/4000oe magstripe
c. Thermal printing/UV spot logo /DOD/Inkjet printing serial/Laser engraving d. serial or UID numbers e. Magnetic stripe(300oe, 2750oe), Barcode f. Encoding and Encryption, Chip encoding g. Anti-metal layer , Back adhesive , Epoxy cover |
||||||
|
|
Corporations, Hotel, Bank, Supermarket, Club/SPA Membership Management,
advertisement, Health care, School, Campus one-card, Loyalty card, Bus- stored value card, Travel, Public transportation, Access Control & Security, freeway collection toll,Parking and Payment, Time Attendance, Event ticketing,Residential management, |
||||||
|
|
Standard size card packing: 200pcs/inner box, 2000pcs or 3000pcs/ctn.
Irregular size(except the standard size): 100pcs/Opp bag and then in carton, or packed per your request. |
||||||
|
Certification
|
RoHS/CE/ISO
|
||||||
|
Lead time
|
7-10 Working days
|
||||||
RFID chips options
We have many kinds of style for choosing, IC card, magnetic stripe card, differrent frequency 125KHz,13.56MHz
and 860-960MHz, and available chips as below are our style for you to choose
and 860-960MHz, and available chips as below are our style for you to choose
|
Work Frequency
|
Protocol
|
Chips available
|
Memory
|
Remark
|
|
LF
125KHz |
ISO11784/85
ISO14223 |
HITAG® µ
|
128 bits/512 bits/1760 bits
|
HITAG® is a trademark of NXP B.V.
|
|
HITAG® S 256
|
256 bits
|
|||
|
HITAG® S 2048
|
2048 bits
|
|||
|
HITAG® RO64
|
64 bits
|
|||
|
HITAG® 1
|
2048 bits
|
|||
|
HITAG® 2
|
256 bits
|
|||
|
HF
13.56MHz |
ISO/IEC 14443 A
|
MIFARE Classic® EV1 Mini
|
320 bytes
|
MIFARE® and MIFARE Classic® are trademarks of NXP B.V.
Cardy is a Registered MIFARE® Partner. |
|
MIFARE Classic® EV1 1K
|
1K bytes
|
|||
|
MIFARE Classic® EV1 4K
|
4K bytes
|
|||
|
MIFARE Ultralight®
|
64 bytes
|
MIFARE® and MIFARE Ultralight® are registered trademarks of NXP B.V. and are used under license.
Cardy is a Registered MIFARE® Partner. |
||
|
MIFARE Ultralight® C
|
192 byte
|
|||
|
MIFARE Ultralight® EV1
|
48 bytes/128 bytes
|
|||
|
MIFARE Ultralight® Nano
|
56 bytes
|
|||
|
MIFARE Ultralight® AES
|
144 bytes
|
|||
|
MIFARE® DESFire® Light
|
640 bytes
|
MIFARE® and MIFARE® DESFire® are registered trademarks of NXP B.V. and are used under license.
Cardy is a Registered MIFARE® Partner. |
||
|
MIFARE® DESFire® EV1 2K
|
2K bytes
|
|||
|
MIFARE® DESFire® EV1 4K
|
4K bytes
|
|||
|
MIFARE® DESFire® EV1 8K
|
8K bytes
|
|||
|
MIFARE® DESFire® EV2 2K
|
2K bytes
|
|||
|
MIFARE® DESFire® EV2 4K
|
4K bytes
|
|||
|
MIFARE® DESFire® EV2 8K
|
8K bytes
|
|||
|
MIFARE® DESFire® EV3 2K
|
2K bytes
|
|||
|
MIFARE® DESFire® EV3 4K
|
4K bytes
|
|||
|
MIFARE® DESFire® EV3 8K
|
8K bytes
|
|||
|
MIFARE Plus® S 2K
|
2K bytes
|
MIFARE® and MIFARE Plus® are registered trademarks of NXP B.V. and are used under license.
Cardy is a Registered MIFARE® Partner. |
||
|
MIFARE Plus® S 4K
|
4K bytes
|
|||
|
MIFARE Plus® SE 1K
|
1K bytes
|
|||
|
MIFARE Plus® X 2K
|
2K bytes
|
|||
|
MIFARE Plus® X 4K
|
4K bytes
|
|||
|
MIFARE Plus® EV1 2K
|
2K bytes
|
|||
|
MIFARE Plus® EV1 4K
|
4K bytes
|
|||
|
MIFARE Plus® EV2 2K
|
2K bytes
|
|||
|
MIFARE Plus® EV2 4K
|
4K bytes
|
|||
|
ISO/IEC 14443 A
NFC Forum T2T/ T4T |
NTAG® 213
|
144 bytes
|
NTAG® is a registered trademark of NXP B.V. and are used under license.
|
|
|
NTAG® 215
|
504 bytes
|
|||
|
NTAG® 216
|
888 bytes
|
|||
|
NTAG® 424 DNA
|
416 bytes
|
|||
|
NTAG® 424 DNA TT
|
416 bytes
|
|||
|
ISO/IEC 15693
ISO/IEC 18000-3 |
ICODE® SLIX-L
|
256 bits
|
ICODE® is registered trademarks of NXP B.V. and are used under license.
|
|
|
ICODE® SLIX
|
896 bits
|
|||
|
ICODE® SLIX-S
|
1280 bits
|
|||
|
ICODE® SLIX2
|
2528 bits
|
|||
|
ICODE® SLI
|
1024 bits
|
|||
|
ICODE® SLI-S
|
2048 bits
|
|||
|
ICODE® DNA
|
2016 bits
|
|||
|
ICODE® ILT-M
|
512 bits
|
|||
|
UHF
860-960MHz |
ISO18000- 6C
|
UCODE® 7
|
0 bits
|
UCODE® is a registered trademark of NXP B.V. and are used under license.
|
|
UCODE® 7m
|
32 bits
|
|||
|
UCODE® 7xm
|
2048 bits
|
|||
|
UCODE® 7xm+
|
2048 bits
|
|||
|
UCODE® 8
|
0 bits
|
|||
|
UCODE® 8m
|
32 bits
|
|||
|
UCODE® 9
|
0 bits
|
|||
|
UCODE® 9xe
|
0 bits
|
|||
|
UCODE® DNA
|
3072 bits
|
|||
|
UCODE® G2iM
|
320/640 bits
|
