Description
|
Physical Characteristics
|
|
|
|
Dimensions
|
178 x 83 x 17 mm / 7.0 x 3.27 x 0.67 in.
|
|
|
Weight
|
~20.46 oz./~580 Grams (device with battery)
|
|
|
Display
|
5.72-inch high definition full display (18:9), IPS 1440 x 720
|
|
|
Battery
|
Main battery: Li-ion, rechargeable, 10000 mAh
Standby: over 600 hours Continuous use: over 16 hours (depending on user environment) Charging time: 3-4 hours (with standard adaptor and USB cable) |
|
|
Touch Panel
|
Multi-touch panel, gloves and wet hands supported
|
|
|
Notification
|
Sound, LED indicator, vibrator
|
|
|
Interfaces
|
USB Type-C, USB 3.1, OTG, extended thimble;
|
|
|
Card slot
|
1 slot for Nano SIM card, 1 slot for Nano SIM or TF card
|
|
|
Audio
|
2 microphones，1 for noise cancellation；1 speaker；receiver
|
|
|
Keypad
|
1 power key, 2 scan keys, 2 volume keys
|
|
|
Sensors
|
Accelerometer sensor, light sensor, proximity sensor, gravity sensor
|
|
|
Communication
|
|
|
|
WLAN
|
IEEE802.11 a/b/g/n/ac, 2.4G/5G dual-band, internal antenna
|
|
|
WWAN (Europe, Asia)
|
2G: 850/900/1800/1900 MHz
2G: 850/900/1800/1900 MHz WCDMA: 850/900/1900/2100MHz TD-SCDMA: A/F(B34/B39) 4G: B1/B3/B5/B7/B8/B20/B38/B39/B40/B41 |
|
|
WWAN (America)
|
2G: 850/900/1800/1900 MHz
3G: 850/900/1900/2100 MHz 4G: B2/B4/B5/B7/B8/B12/B13/B17/B28A/B28B/B38 |
|
|
Bluetooth
|
Bluetooth 4.0
|
|
|
Vo-LTE
|
Support Vo-LTE HD video voice call
|
|
|
GNSS
|
GPS/AGPS, GLONASS, BeiDou, Galileo, internal antenna
|
|
|
Developing Environment
|
|
|
|
Operating System
|
Android 12; GMS, 90-day security updates, Android Enterprise Recommended, Zero-Touch, FOTA, Soti MobiControl, SafeUEM supported.
Committed support for a future upgrade to Android 12, 13, and Android 14 pending feasibility |
|
|
SDK
|
Support Android/iOS
|
|
|
Language
|
Java
|
|
|
Tool
|
Eclipse / Android Studio
|
|
|
Performance
|
|
|
|
CPU
|
MTK 6762 - 8 Core
|
|
|
RAM+ROM
|
3 GB + 32 GB / 4 GB + 64 GB
|
|
|
Expansion
|
Supports up to 128 GB Micro SD card
|
|
|
Barcode Scanning (Optional)
|
|
|
|
2D Scanner
|
Zebra: SE4710/SE2100; Honeywell: N6603; E3200; IA166S; CM60
|
|
|
1D Symbologies
|
UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.
|
|
|
2D Symbologies
|
PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US
Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX),etc. |
|
|
NFC
|
|
|
|
Frequency
|
13.56 MHz
|
|
|
Protocol
|
ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.
|
|
|
Chips
|
M1 card (S50, S70), CPU card, NFC tags, etc.
|
|
|
Range
|
3-5 cm
|
|
|
User Environment
|
|
|
|
Drop Specification
|
Multiple 6 ft./1.8 m drops to concrete
|
|
|
Tumble Specification
|
500 cycles (1000 drops, 1.6 ft./0.5 m) at room temperature
|
|
|
Operating Temp.
|
-4°F to 131°F / -20 ℃ to +55 ℃
|
|
|
Storage Temp.
|
-40°F to 158°F / -40 ℃ to +70 ℃
|
|
|
Humidity
|
5 - 95% RH non condensing
|
|
|
Sealing
|
IP65 (spray) and IP67 (submersion)
|
|
|
ESD
|
±15 KV air discharge, ±8 KV conductive discharge
|
|
|
UHF RFID
|
|
|
|
Engine
|
CM710-1 module based on Impinj E710
CM2000-1 module based on Impinj Indy R2000 |
|
|
Frequency
|
865-868 MHz / 920-925 MHz / 902-928 MHz
|
|
|
Max Read Range
|
Impinj E710 chip:
26m (Impinj MR6 tag, size 70 x 15mm) 28m (Impinj M750 tag, size 70 x 15mm) 30m (Alien H3 Anti-Metal tag, size 130 x 42mm) Impinj R2000 chip: 24m (Impinj MR6 tag, size 70 x 15mm) 24m (Impinj M750 tag, size 70 x 15mm) 28m (Alian H3 Anti-Metal tag, size 130 x 42mm) |
|
|
Protocol
|
EPC C1 GEN2 / ISO18000-6C
|
|
|
Antenna
|
Circular polarization (-5 dBi)
|
|
|
Fastest Read Rate
|
1200+ tags/sec (circular polarization)
|
|
|
Optional Accessories
|
|
|
|
Accessories
|
Wrist Strap; Rubber Bumper; Charging Cradle
|
|
Product Description
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
FAQ
Q1: Are you manufacturer?
A: Yes, we are manufacturer. Our products are patented, design, hardware, mold, assembly are finished by our own team.
Q2: Can I choose multiple function into 1 device?
A: Yes, different functions depending on the product model, optional functions:RFID (LF/HF/UHF) Fingerprint / Bar code scanner, etc.
Q3: What codes can be read by the handheld?
A: Support code type: PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse Maxicode, QR Code, MicroQR, QR Inverse, Aztec, Aztec Inverses, Han Xin, Han Xin Inverse.
Q4: What is the MOQ?
A: 1 set to test sample is acceptable.
A: 1 set to test sample is acceptable.
Q5: What's your products warranty?
A: 1 year warranty.
Q6: How to repair the device if any problem?
A: We will provide technical support online to solve problem, for the hardware problem, we could send the parts or components and teach customer to fit or send back to us to fix it.
