Card Type BLE iBeacon Tags for Asset Management Low Power nRF52 Ibeacon nRF52810 small size IOS BLE Beacon
Product Description
nRF52810 beacon is a portable iBeacon tag with ultra low power chipset NRF52810 and BLE 5.0 technology . The nRF52810 SoC is a powerful, highly flexible ultra-low power multi-protocol SoC ideal for Ble low power, ANT and 2.4GHz ultra low power wireless applications.
|
Parameter
|
||||
|
Chip number
|
NRF52810
|
Description
|
||
|
Working frequency
|
1.7-3.6v
|
|||
|
Number of channels
|
40
|
|||
|
Modulation
|
GFSK
|
|||
|
Output power
|
-20dBm- + 4dBm
|
configurable programming
|
||
|
Emission current
|
4.6mA
|
POWER is 0dBm, which is related to output power
|
||
|
Receive sensitivity
|
-96dBm
|
High-gain mode
|
||
|
Receive current
|
4.6mA
|
High-gain mode
|
||
|
Standby current
|
0.3uA
|
deep sleep, can only interrupt wake up
|
||
|
Transmission rate
|
1Mbps, 2Mbps
|
determined by software
|
||
|
Chip Flash
|
192KB
|
|||
|
Chip RAM
|
24KB
|
|||
|
Antenna form
|
PCB antenna
|
|||
|
Communication distanc
|
> 50m
|
determined by transmit power, default is 0dBm
|
||
|
Storage temperature
|
-40-125 ℃
|
|||
|
Working temperature
|
-25-75 ℃
|
Ble working temperature
|
||
|
Battery model
|
CR2032
|
Replaceable battery
|
||
|
Size
|
43 × 7 × 27mm
|
Length x width x height
|
||
Application
1.Indoor Positioning 2.Parking management 3.Temperature and humidity monitoring 4.Flow analysis 5.Light detection 6.Asset Management 7.2.4GHz Ble Low Power System 8.Home and building automation 9.Sports and leisure equipment 10.Consumer electronics 11.Human interface device
App
beacon Tool(iphone)to connect the beacon.
You can through this app to change these paraments when this beacon is adversting.
Press and hold for 3 seconds. The indicator flashes three times to indicate that it is broadcasting. Press and hold for 3 seconds
again The indicator flashes one time to indicate that it is no broadcasting.
Through the APP you can set the UUID,Major,Minor
You can through this app to change these paraments when this beacon is adversting.
Press and hold for 3 seconds. The indicator flashes three times to indicate that it is broadcasting. Press and hold for 3 seconds
again The indicator flashes one time to indicate that it is no broadcasting.
Through the APP you can set the UUID,Major,Minor
