Description
Product Description
Specification
|
Parameter
|
||
|
Dimension
|
230×146×20±2mm
|
|
|
Weight
|
670 g
|
|
|
Screen
|
8 inch IPS HD screen, resolution 800*1280
|
|
|
Touch screen
|
Corning Gorilla Three Generation Industrial Grade Multi-touch Capacitive Screen
|
|
|
Expansion slot
|
1 SIM card slot
|
|
|
1 MicroSD (TF) card slot
|
||
|
Support 2 PSAM cards, (4 PSAM can be expanded and customized)
|
||
|
Communication Interface
|
1 Type-c interface
|
|
|
1 3.5 stick plug into the charging port
|
||
|
1 standard USB interface
|
||
|
Support wired Internet access via RJ45, data transmission (optional)
|
||
|
Audio
|
Support voice broadcast
|
|
|
Indicator light
|
Network indicator light
|
|
|
Keyboard
|
Function keys
|
|
|
Camera
|
Front 5 million pixel camera, rear 13 million pixel camera, with flash, auto focus function
|
|
|
Flashlight
|
Low power LED lighting, emergency use
|
|
|
GPS Navigation
|
Built-in GPS global positioning system, error range ±5m
|
|
|
Performance parameter
|
||
|
CPU
|
Octa-core 64-bit Coretex-A53
|
|
|
RAM& ROM
|
RAM：2GB ROM：16GB （Standard）
RAM：3GB ROM：32GB （Option） |
|
|
OS
|
Android 7.0
|
|
|
Expanded memory
|
Support 128GB Micro SD CARD
|
|
|
Data communication
|
||
|
4G
|
TD-LTE Band38/39/40/41；
FDD-LTE Band 1,2,3,4,7,17,20； |
|
|
3G
|
WCDMA( 850/1900/2100MHz);
|
|
|
2G
|
GSM/GPRS/Edge（850/900/1800/1900MHz）
|
|
|
WIFI
|
2.4G/5G dual frequency, in line with IEEE802.11a/b/g/n
|
|
|
Bluetooth
|
Comform Bluetooth 4.0
|
|
|
Working environment
|
||
|
Operating temperature
|
-20℃～50℃
|
|
|
Storage temperature
|
-20℃～70℃
|
|
|
Relative humidity
|
5%～95%Non-condensing
|
|
|
IP Rating
|
Host IP67
|
|
|
Battery performance
|
||
|
Battery capacity
|
8000mAh lithium polymer battery
|
|
|
Standby time
|
Turn off wireless communication and other functions can stand 720 hours
|
|
|
Charging time
|
Less than 8 hours
|
|
|
Working time
|
10 hours or more (once fully charged)
|
|
|
Barcode collection (optional)
|
||
|
1D |
1D laser scanning module
|
Honeywell N431X/ others
|
|
Support 1D barcode type
|
Code 39、Code 93、Code128、Codebar、EAN- 13、EAN- 8、UPC-A、UPC- E、ITF 14、UCC/EAN- 128、ITF25、Matrix 25、EAN-128、ISBN等
|
|
|
2D
|
2D scanning engine
|
Honeywell-6603/others
|
|
Support 2D barcode type
|
PDF417, MicroPDF417, Composite, RSS, TLC-39,Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes,US PostNet,US
Planet, UK Postal, Australian Postal,Japan Postal, Dutch Postal e.g. |
|
|
RFID（Optional）
|
||
|
UHF
|
Frequency
|
915MHz、865MHz（865-868MHz或902-928MHz）
|
|
Protocol
|
For EPC C1 GEN2/ISO18000-6C protocol
|
|
|
Distance
|
Optional 3-5m distance (related to label and environment)
|
|
|
HF
|
Frequency
|
13.56MHz
|
|
Protocol
|
For ISO15693, ISO14443 dual protocol
|
|
|
Distance
|
0-7CM（Related to RFID tag and environment）
|
|
|
LF RFID
|
125K/134.2K Animal ear tag
|
|
|
HF（CPU CARD）
|
Support CPU card reading and writing, use with PSAM
|
|
|
Active 2.45G
|
200 meters away, 200 tags can be read at one time
|
|
|
ID card reading (optional)
|
||
|
Built-in module
|
Security encryption module of the second generation certificate of the Ministry of Public Security
|
|
|
Tips:
|
For more information, please consult online customer service, thank you
|
||||||
