Air Conditioning Drainage Pump JF091011 Condensate Water Lift for VRV Draining 1P to 10P Power Unit Motor Conditioner Parts

$36.00  - $63.00
color:  JF09
packaging types:  ≥50 pieces
Quantity

Description

Product Paramenters
model
JF09
JF10
JF11
Functional differences
Long running version
Intelligent control model
Intelligent dual control model
Rated voltage/frequency
220V-240V~50/60Hz
220V-240V~50/60Hz
220V-240V~50/60Hz
working voltage
rated voltage±10%
rated voltage±10%
rated voltage±10%
Rated current
≤0.12A(220V~50/60Hz)
≤0.12A(220V~50/60Hz)
≤0.12A(220V~50/60Hz)
Input power
≤12W(220V~50/60Hz)
s12W(220V~50/60Hz)
≤12W(220V~50/60Hz)
Insulation level
E
E
E
temperature protector
BR-A1D 140C
BR-A1D 140℃
BR-A1D 140℃
Operating temperature
140℃±5℃
140℃±5℃
140℃±5℃
Reset temperature
95℃±5℃
95℃±5℃
95℃±5℃
Maximum head
Max.1.2m
Max1.2m
Max.1.2m
Operation level
Discontinuity
Discontinuity
Discontinuity
Storage tank capacity
300ml
300ml
300ml
maximum flow
Max60L/h
Max60L/h
Max60L/h
Operating noise
≤25dB
≤25dB
≤25dB
Applicable air conditioner power
10P
10P
10P
Environmental temperature for use
0-50℃
0-50℃
0-50℃
Products Description
Packing & Delivery
