Description
Product Description
|
Physical Parameter
|
||
|
Size
|
87mm×55mm×7mm
|
|
|
Material
|
ABS+PC
|
|
|
Color
|
White gray, off-white (can be customized)
|
|
|
Weight
|
26g
|
|
|
Packing
|
Corrugated box (can be customized)
|
|
|
Environmental Parameters
|
||
|
Working Humidity
|
<95%
|
|
|
Working Temperature
|
-20℃~ 60℃
|
|
|
Storage Temperature
|
-40℃~ 85℃
|
|
|
Protection Level
|
IP68
|
|
|
Performance parameter
|
||
|
Static (standby) working current
|
<5uA
|
|
|
Operating Voltage
|
3.0V
|
|
|
Battery
|
Cr2032 button battery*2(Can be changed)
|
|
|
Working frequency
|
2.4GHz-2.5GHz
|
|
|
Working Current (Transmit signal)
|
<18mA (Pulse mode)
|
|
|
Battery Life
|
2-5 Year ((theoretical value)
|
|
|
Collision Ability
|
>200PCS
|
|
|
Transmit Time
|
Active 1 time per second / Passive 3 to 4 times per second
|
|
|
Receiving sensitivity
|
-800dBm ~ -90dBm
|
|
|
Working Mode
|
Read-only
|
|
|
Working Method
|
Active/Passive /Active-passive combination
|
|
|
Low/High Frequency
|
125K/13.56Mhz (Optional)
|
|
|
Disassemble alarm
|
Yes (can be removed)
|
|
Product Summary
Drawer card can have multiple working frequencies. 2.4GHz can be identified from a long distance, making it more secure. Electronic tag card needs to be triggered to be recognized by RFID remote reader. 125Khz or 13.56Mhz can also be added as required by customers.
Product Feature
● Reading: Compared with bar code, there is no need to scan in a straight line, the reading speed is faster, and multi-tag recognition and motion recognition can be performed; ● Security: Anti-tampering, encryption algorithm and authentication to ensure data security and durability; ● Penetrability: it can penetrate any metal automobile explosion-proof film. Put card in the vehicle, and can be automatically identified by the reader without opening the window; ● If make Data storage: the dual frequency function enables the electronic label to have data storage function, making it more widely used. ● Durability: no mechanical failure, fully sealed structure; with the trigger, the battery can be used for 3 years. ● Tag ID number: 10 bytes; ● Reading Type: Read-only; ● Waterproof: IP68; ● Anti-suddenness: Advanced anti-collision technology can identify more than 200 tags at the same time; ● High speed recognition: recognition speed can reach 60 km/h; ● High anti-interference: no special requirements for various interference sources on the site; ● Anti-electromagnetic interference: 10V/m0.1 ~ 1000MHz AM, AM electromagnetic wave.
Applications ● Location of personnel in the case handling area ● Positioning of nursing home staff ● Building, community card ● Prison card or regional personnel positioning ● Positioning of construction personnel ● Personnel access management ● School student and teacher attendance management ● Automatic identification personnel management system
