Description
Product Description
Specification
|
Electrical Specifications
|
||
|
Frequency
|
860-960MHz
|
|
|
Gain
|
5dBi
|
|
|
Beam width
|
Hor:105° Ver:90°
|
|
|
Polarization
|
Circular
|
|
|
VSWR
|
≤1.4
|
|
|
F/B Ratio
|
≥20
|
|
|
Impedance
|
50Ω
|
|
|
Maximum power
|
100W
|
|
|
Lightning protection
|
DC Ground
|
|
|
Connector
|
SMA-Male
|
|
|
Mechanical Specifications
|
||
|
Dimension
|
120*120*8mm
|
|
|
Net weight
|
0.3kg
|
|
|
Packing size
|
15.5*15.5*3.5cm
|
|
|
Gross weight
|
0.6kg
|
|
|
Radome material
|
PCB
|
|
|
Radome colour
|
Black
|
|
|
Operating temperature
|
-20-60℃
|
|
