Description
Accuracy
≤ ± 0.5% of full range (including non-linear, hysteresis and non-repeatability)
Long-term stability
25 ℃ ≤ 0.4% full range/year
Thermal effects
≤ ± 0.04% full range/℃
Output
2-wire 4-20 mA
Power supply
10 to 32 Vdc (typically 24 Vdc)
Load
≤ (supply voltage-10 V)/ (0.02 A) Ohms
Material
304 stainless steel, sealing material NBR
Pressure connection
G1/4”/,1/2
Electrical connection
DIN43650A
Certification
CE
Protection standard
IP65
FAQ
1、Is your company a production-oriented enterprise？
Our own factory is located in Yanjiao, Hebei, and has passed ISO9001 certification
2、What kind of products does your company provide and does it support OEM？
We provide various sensors, transmitters,switches, including temperature, humidity, pressure, differential pressure, liquid level, illumination, air quality, etc.
3、How to obtain samples？
You should communicate with me, confirm the product model and delivery time, obtain free samples or pay part of the sample fees
4、How to get the latest price？
You communicate with me to provide product application scenarios and requirements,and quantity
5、Delivery time？
Usually one week，the specific time shall be subject to the actual communication
