3.6-5VDC 76-108M FM Stereo Receiver Squelch 5W Amplifier Digital Stereo FM Receiver Module FM Radio Receiver
Description
The main parameters:
| Input voltage | 3.6-5VDC |
| Input current | <1A (including power amplifier) |
| Receiving range | 76-108M |
Output speaker power: 5W (2 ohm speakers), 3W (4 ohm speakers), 2W (8 ohm speakers)
Input sensitivity: -106dBm
SNR: 64dB
THD: <0.3%
Size: FM receiving board size: 65mm (length) * 30mm (width) * 15mm (height)
LCD1602 display size: 85mm * 53mm.
Infrared cable length: 10CM.
Weight: 85g / set.
The main function:
1, can pre-store 50 stations.
2, with power-off memory function.
3, volume, frequency remote control adjustable.
4, with automatic squelch function, while the squelch function can be manually turned on or off, and the squelch sensitivity can be adjusted.
5, with 5W built-in amplifier, you can directly drive the speaker. The amplifier can be turned on or off manually.
6, with software subwoofer adjustment.
7, with a mute function.
This kit shipping list:
1, the finished motherboard is a piece.
2, LCD1602 LCD screen.
3, infrared remote control (without battery), please install the battery separately after receiving (CR2025 big supermarkets are available for sale)
4, infrared receiver head
