Products Description
Linear scanning radar (XX1400)
The XX1400 linear millimeter wave radar adopts a new generation of international linear radar tracking and scanning detection technology, which has long detection distance, strong detection ability, up to 1024 target tracking data, and high target positioning accuracy. The radar sensor adopts an integrated design, which is more convenient to install. The IP67 safety protection level design can adapt to various special application environments and meet all-weather working needs. The multi angle remote automatic adjustment mechanism can meet the special needs of various line types.
Product characteristics:
*Comprehensive perception Linear millimeter wave radar, due to its use of imageable millimeter wave detection technology, can achieve high reliability in detecting moving and stationary target objects, and can meet the ability of polymorphic potential perception detection. *Accurate control Linear millimeter wave radar has many advantages such as long detection distance, wide coverage range, high target resolution, strong anti-interference ability, and accurate positioning accuracy. Through the system platform, precise detection and control capabilities can be achieved. *All-weather work Linear millimeter wave radar, with its absolute advantages of penetrating dust fog, rain and snow, and not affected by bad weather, can meet the super ability of "all-weather all day" work. *Full data collection
Linear millimeter wave radar uses multi beam time-sharing scanning imaging technology to accurately classify target objects and collect real-time data covering the detection range of the radar to meet different scene applications. *The coverage range, area, and angle can be precisely adjusted The linear millimeter wave radar adopts a unique structural design internally. After the equipment is installed, it can automatically or manually adjust the detection range, detection area, elevation angle, and horizontal angle covered by the radar remotely to meet different scene and environmental applications, and maintain high-performance detection and perception capabilities. *Designed for special application environments The linear millimeter wave radar adopts an ultra-high resolution imaging millimeter wave radar perception unit, with higher distance resolution, angle resolution, and velocity resolution, which can effectively solve clutter interference. The new algorithm makes it more outstanding in special environments (such as tunnels, bends, rainy days), and can support pedestrian wandering detection, obstacle object detection, etc. *Automatic lane drawing The device supports automatic drawing of lane areas and can automatically draw lane routes based on the driving trajectory of on-site vehicles. *Can save more construction costs Linear millimeter wave radar can adapt to more application environments and special application requirements, achieving maintenance free, debugging free, and calibration free, greatly reducing the overall investment budget of the project. In addition, the radar supports network disconnection maintenance and remote maintenance (3-year free remote maintenance). All working parameters, coverage area, coverage range, and coverage angle of the radar can be remotely automatically or manually adjusted, which greatly reduces the cost of equipment maintenance in the later stage.
Applications:
highways, high-speed railways, security, industrial
Specifications
|
Product Name
|
Linear millimeter wave radar (XX1400)
|
|
Working frequency
|
80-81 GHZ (FMCW), support adjustable frequency conversion function, with cascaded anti-interference function
|
|
frequency modulation bandwidth
|
1GHz
|
|
Detection distance
|
1400m
|
|
Object detection type
|
pedestrian, vehicle
|
|
Target tracking number
|
1024
|
|
Detection lane
|
≥12 lanes
|
|
Device positioning method
|
GPS/ Beidou positioning
|
|
Radar timing mode
|
Beidou /GPS/NTP
|
|
CPU
|
Eight-core 64-bit processor, the highest frequency 2.7GHz
|
|
GPU
|
Octa-core ARM Mali-G610 MC4
|
|
AI computing power
|
6TOPS
|
|
Running memory
|
32GB
|
|
Memory expansion
|
Up to 128GB TF card
|
|
Communication methods
|
support three modes: 4G, WIFI, and 100M/1000M (adaptive) network ports
|
|
Operating voltage
|
24VDC
|
|
Power consumption
|
≤30W
|
|
MTBF
|
100000h
|
|
Working temperature
|
-40 ℃~+70 ℃
|
|
Protection level
|
IP67
|
