Description
12V 24V 36V 48V 28A Sensorless BLDC Motor Driver 3 Phase No Hall Brushless BLDC Electric Motor Driver with Switch
Product Description
Input voltage
DC12V24V and 36V48V can be optional
Output current
28A
Speed regulation method
potentiometer (linear)
Speed range
0-100%
Positive and negative function
yes (manual switch)
Overcurrent protection
yes (30A)
Shell size
length*width*height 150MM*85MM*45MM
Net weight
500g
Mainboard installation size
center distance 165MM
Potentiometer installation opening
10MM
Note
1, This governor has 12V24V universal and 36V48V universal can optional. default delivery is 12V24V 2, This governor is not suitable for high-speed motors recommended within 6000 rpm
